When used in distribution pipelines, it can achieve pasteurization, sterilization, and instantaneous cooling at cold-use points, reducing the risk of cross-contamination in the system, making it an ideal choice for system applications.

Technical Description:

1. Designed and manufactured strictly in accordance with TEMA/ASME BPE standards, complying with cGMP and FDA regulations.

2. Double-tube sheet design to prevent cross-contamination;

3. Full drainage design, no residue, no dead corners;

4. Main body electropolished, with Ra ≤ 0.35μm on the material contact side;

5. Imported FKM sanitary sealing material is used, with FDA/ASME certification documents provided for support.

6. Multi-flow design (single, dual, quad), compact structure, higher efficiency;

7. The tube side and shell side are thoroughly cleaned with no harmful residues remaining.

8. Provide a complete validation documentation system;
