XSG-8 Flash Drying System (with technical agreement, subject to the technical agreement) Assembly
Flash Evaporator Tower Blower, Airflow 7000-10000m³/H, Air Pressure 3000Pa, 4-72-5A-11KW
Attachment: Motor P=11kW, 380V, explosion-proof grade: dⅡBT4
Flash Evaporation Induced Draft Fan, Air Volume 8000~9500 m³/h, Air Pressure 6500~7000 Pa, 9-26-5.6A-30KW
Q235 Note: Motor P=30kW, 380V, variable frequency, explosion-proof grade: dⅡBT4

Flash drying tower φ800, inner wall thickness t=2 mm
Outsourced carbon steel t=2.0mm, XSG8 cooling jacket stainless steel 4mm
Carbon steel flange and base t=16mm, main motor, P=5.5KW
Air filter 1000X1000X400mm (4 square meters)
Radiator 60㎡ × 5 pieces = 300㎡
Adopting a U-tube design, it offers high pressure resistance and high thermal efficiency.
Screw feeder, feeding capacity 500 kg/h, conveying pipe Φ159, variable frequency speed regulation, hopper, screw blade t=3mm, double screw.
Note: Motor P=3kW, 380V, variable frequency, explosion-proof grade: dⅡBT4

Swirl Dryer Φ1150-Φ950 t=2mm
Cyclone separator CZTφ1000 t=2mm CZTφ1000
Rotary valve TFGFY3L: the material of parts in contact with the material is 304.
Note: Motor P=0.75kW, 380V, explosion-proof grade: dⅡBT4

Dust Collector, Pulse Jet Bag Filter, 500-mesh Bags, Filtration Area 110 m², MC98-3000

Air volume: 1.2 m³/min Pressure: 0.7～0.8 MPa
