Sodium Sulfate Anhydrous Pulse Airflow Dryer

1. Material Name: Anhydrous Sodium Sulfate

2. Output: 800-1000kg/h

3. Initial moisture content 5-7% (free water, excluding crystalline water)

4. Final moisture content ≤ 1%

5. Heat source: 230℃ thermal oil

7. Material properties: separated by centrifuge, particle size approximately 0.4mm, specific gravity 2.6g/cm³.

8. Environmental conditions: 760 mmHg, t0 = 10~40°C

II. System Composition and Functional Description of Pulse Airflow Dryer

1. Name: Pulse Airflow Dryer

2. Model QG100 Pulse Airflow Dryer

3. Output: 800-1000 kg/h

4. Operating temperature: Inlet air: t1 ≈ 200°C, Mixing temperature: t2 = 100-110°C, Outlet air:

t3 ≈ 90°C

5. Operating pressure: -8000 Pa

6. System material receiving rate ≥ 99.5%

7. External dimensions of pulse pneumatic dryer (mm): Φ280/350H17000

8. The weight of the pulse pneumatic dryer is 2.2 tons.

9. SUS304 at material contact points
