It is widely used in the production industries of cement, silicate products, new building materials, refractory materials, material chemistry laboratories, bio-fertilizers, non-ferrous metal beneficiation, as well as glass and ceramics, for dry or wet mixing of various ores and other grindable materials. It is extensively applied in the grinding and mixing processes during the processing of electronics, ceramics, coatings, glass powder, fluorescent materials, non-metallic minerals, pharmaceuticals, electronic materials, magnetic materials, equipment batteries, biological cultivation, food packaging, and battery materials.
One,Product Parameters
Model | GMS5-1Z | GMS10-1Z | GMS5-2Z | GMS5-4Z | GMS10-4Z | GMS10-8Z |
The volume of the mixing tank. | 500ml-5L | 500ml-10L | 500ml-5L | 500ml-5L | 500ml-10L | 500ml-5L |
Roller diameter*Length | Φ58*288 | Φ68*349 | Φ58*290 | Φ58*290 | Φ68*（349*2） | Φ68*（349*2） |
Powerkw） | 0.25 | 1.1 | 0.75 | 0.75 | 1.5 | 3 |
The spacing of the handwheel is adjustable. | Adjustment of handwheel spacing | 67-230 | 67-280 | 67-280 | 67-230 | 67-302 |
Adjustable jar diameter | Φ58-Φ288 | Φ60-Φ280 | Φ70-Φ260 | Φ70-Φ260 | Φ60-Φ280 | Φ60-Φ280 |
Number of layers/workstation | Single layerSingle station | Single layerSingle station | Single layer/Dual-station | Single layerFour-station | Single layerFour-station | Double-deckerEight-station |
Power supply (v/hz） | 220v/50hz | 220v/50hz | 220v/50hz | 220v/50hz | 380v/50hz | 380v/50hz |
Roller speed | 5-900 | 5-1200 | 5-1000 | 5-1000 | 5-1200 | 5-720 |
Transmission method | Synchronous belt | Synchronous belt | Synchronous belt | Synchronous belt | Synchronous belt | Synchronous belt |
Number of rollers | Two pieces | Two | Two pieces | Three | Three | Six Roots |
