YGSM-50L High Viscosity Sand Mill

Product Introduction

⊙Specially designed tungsten steel stirrer, high wear resistance and corrosion resistance;

⊙Dynamic + static gap discharge, large area, no clogging;

⊙Automatic hydraulic propulsion piston device, effectively adjusting the filling ratio of grinding media;

⊙ Reduce the starting current to ensure the equipment operates under reasonable conditions;

⊙Imported double-end face mechanical seal, reliable operation;

⊙The grinding cylinder features dual-screw forced cooling, ensuring effective grinding of materials within a controlled temperature range.

⊙Special lifting device for easy maintenance and assembly/disassembly;

⊙Grinding fineness: 15-2 μm.

Net capacity 50L

Regulating cylinder volume 11L

Separator type Dynamic+Screen ring

Separator gap 0.5MM

Cooling water flow rate About850L/H

Cooling water temperature 8-15℃

Cooling water pressure 0.4mpa

Cooling water inlet and outlet ¾“

Feed inlet pressure gauge Explosion-proof type0-0.6MPa (adjustable)

Discharge port thermometer Explosion-proof type0-100°C (adjustable)

Size of grinding media0.8-2.0mm (optional)

Weight of grinding media 125kg
