Equipment grinding chamber

Total capacity of the equipment grinding chamber:0.75L

Inner Cylinder Material: Standard is Zirconia

Grinding turbine rotor: standard configuration is zirconia.

Cooling method: Cooling water dissipates heat through the spiral water channel of the grinding barrel.

Dual cooling

Mechanical seal

Double-ended main mechanical seal+DBD Second seal

with cooling system

Mechanical seal overall bracket material: stainless steel304）

With pressure protection

Mechanical seal coolant delivery: circulating natural cooling

With liquid level detection

Mechanical seal cooling protection: monitored via magnetic level gauge.

With pressure protection

Maximum feed pressure that the mechanical seal can withstand:3.5-4 kilogram

Effective volume

0.5L

Dispersion and Grinding Mechanism

Pin-type

Material Conveying

American imported peristaltic pump (equipped with solvent-resistant hose)

Separation method

Dynamic centrifugal separator gap0.05mm(Size optional)

Large area with multiple gaps

Separation Gap: Standard configuration is zirconia

Spindle

Material:2cr13

Quenching and tempering, heat treatment

Manufacturing precision: according toGB6 Implementation at the standard level

Bearing:NSK

grinding media

Material: Pure Zirconia
Specifications:0.1mm The above input quantities are:75%-85%

Customer purchased on their own, selecting the appropriate one based on fineness requirements.
Big and small beads.

Equipment coating color

According to our company's standard color.

The customer may specify.

Feed pipe

The supplier shall configure a solvent-resistant feed hose.1 Root

Pressure

Greater feed pressure:2KG

Electrical appliances

Variable frequency speed regulation/4KW-2P,300-2500rpm, Inverter power:4KW

Variable frequency start, touch screen operation (brand: Kunlun Tongtai)

Explosion-proof optional

The unit comes with a built-in chiller.1.5 Okay, here is the translation of the Chinese character "匹" into English, keeping the format as requested. piece3Lift interlayer mixing tank, pneumatic mixer

Motor inverter brand, standard configuration: Wannan Motor/Southern Anhua Frequency Converter

Customers can specify the brand for motors and frequency converters.

Overall Dimensions

1250X950X1750Net weight:620kg
