Hydraulic Lifting Dispersion Mixer (with Wall Scraper)

Product Introduction

Scraper-type disperser is A product developed based on a single-shaft disperser, featuring dispersion and wall-scraping functions. During the dispersion process of the wall-scraping disperser, the wall scraper rotates along the wall of the container, creating a certain radial stirring effect. At the same time,The scraper made of PTFE material can effectively scrape off materials on the barrel wall, demonstrating excellent adaptability to medium-to-high viscosity and thixotropic materials. The final product is discharged cleanly, and the material barrel is easy to clean.

Product Features:

1. Dispersion linear speed above 20m/s, high dispersion efficiency;

2. Variable frequency speed regulation, easy to operate;

3. The scraper design effectively resolves the issue of material adhesion to the wall, ensuring clean discharge and convenient maintenance.

4. Customizable for various types of non-standard products, such as explosion-proof, sealed vacuum, multi-cylinder single-machine, etc. The material can be customized as required, including SS21/SS316L stainless steel.

Working principle

The dispersion disc operates at high speed, causing the material to form a ring-shaped flow, generating a strong vortex that spirals downward to the bottom of the vortex. Intense shear, impact, and friction occur between particles, achieving rapid dispersion and dissolution. The frame-type wall-mounted stirring mechanism scrapes the cylinder walls, accelerating material circulation and improving dispersion efficiency. The hydraulic pump drives the hydraulic plunger to lift and lower, moving the entire transmission mechanism and working group accordingly.

Technical Parameters
