Hydraulic Lifting Disperser
Product Introduction
It is mainly used for crushing, dispersing, emulsifying, and mixing liquid raw materials of different viscosities in a slurry form. Through the high-speed operation of the upper and lower serrations of the dispersing disc, the materials undergo rapid and intense shearing, impact, crushing, and dispersion, achieving the functions of quick mixing, dispersion, and refinement.
Product Features:
1. This machine is suitable for industrial production use;
2. The hydraulic lifting is stable and convenient; the structure is sturdy and durable;
3. Customizable sealing and explosion-proof functions;
4. It can be installed either on the ground or on a platform.
5. Non-standard customization can be carried out according to customer requirements.
Working principle
The serrated circular dispersion disc operates at high speed within the container to complete the processes of solid-liquid dispersion, wetting, de-agglomeration, and stabilization. It causes the slurry to form a rolling annular flow, generating a strong vortex, with particles on the blade surface descending in a spiral pattern into the vortex.
Bottom; at the edge of the dispersion discA turbulent zone forms at 2.5-5mm, where the slurry and particles undergo intense shearing and impact; outside this zone, two flow streams are generated, allowing the slurry to be fully circulated and agitated; below the dispersion disc of the disperser,
When it is in a laminar flow state, slurry layers with different flow velocities diffuse into each other, thereby achieving a dispersing effect.
Technical Parameters
Model | Power | Speed | Lifting stroke | Processing capacity | Dispersion disc diameter | Overall Dimensions | Weight |
kw | rpm | mm | L | mm | mm | kg | |
YYFS-2.2 | 2.2 | 1440 | 600 | 50～150 | 150 | 1300×800×1500 | 400 |
YYFS-4 | 4 | 1440 | 600 | 50～200 | 200 | 1600×800×1850 | 450 |
YYFS-5.5 | 5.5 | 1440 | 800 | 80～250 | 200 | 1850×800×1850 | 600 |
YYFS-7.5 | 7.5 | 1440 | 800 | 100～300 | 250 | 1850×800×1850 | 700 |
YYFS-11 | 11 | 1440 | 800 | 100～400 | 250 | 1850×800×1850 | 750 |
YYFS-15 | 15 | 1440 | 800 | 150～500 | 300 | 1850×800×1850 | 800 |
YYFS-18.5 | 18.5 | 1440 | 1100 | 200～800 | 300 | 2150×900×2100 | 1000 |
YYFS-22 | 22 | 1440 | 1100 | 200～1000 | 300 | 2150×900×2100 | 1100 |
YYFS-30 | 30 | 1440 | 1100 | 300～1500 | 350 | 2150×900×2100 | 1200 |
YYFS-37 | 37 | 1440 | 1300 | 400～2000 | 400 | 2550×1000×2450 | 1300 |
YYFS-45 | 45 | 1440 | 1300 | 500～2500 | 450 | 2550×1000×2450 | 1400 |
YYFS-55 | 55 | 1440 | 1300 | 600～3000 | 450 | 2700×1200×2800 | 1500 |
YYFS-75 | 75 | 960 | 1500 | 800～4000 | 500 | 3200×1200×3200 | 3000 |
YYFS-90 | 90 | 960 | 1600 | 1000～5000 | 550 | 3400×1200×3400 | 3500 |
YYFS-132 | td style="padding: 7px 0px; border-color: currentcolor rgb(0, 0, 0) rgb(0, 0, 0) currentcolor; border-style: none solid solid none; border-width: medium 1px 1px medium; background: rgb(255,
