extruder
Product Introduction
Extruders are typically used in conjunction with containers to help discharge high-viscosity materials from the container, followed by metering, dispensing, and filling. The pressure and platen height are adjustable, and both pneumatic and hydraulic options are available.
The discharge position can be connected to a metering device to achieve quantitative discharge, with the option of top or bottom discharge methods.
Technical Parameters
Model/Model number | Extrusion disc diameter | Pressure per unit area | Design pressure | Squeeze in the itinerary | The cylinder diameter of the lifting cylinder. | Lifting stroke |
mm | kg/cm2 | T | mm | mm | mm | |
YYJC-2 | 180 | 12 | 3.1 | 250 | ||
YYJC-5 | 240 | 12 | 5.4 | 350 | ||
YYJC-10 | 310 | 12 | 9.1 | 400 | ||
YYJC-20 | 350 | 12 | 11.5 | 450 | ||
YYJC-30 | 400 | 12 | 15.1 | 500 | 80 | 200 |
YYJC-60 | 500 | 12 | 23.6 | 600 | 100 | 300 |
YYJC-100 | 596 | 12 | 33.5 | 700 | 120 | 300 |
YYJC-200 | 750 | 12 | 53.0 | 850 | 120 | 800 |
YYJC-300 | 836 | 12 | 65.8 | 1000 | 140 | 1000 |
YYJC-500 | 1000 | 12 | 94.2 | 1200 | 160 | 1200 |
YYJC-1000 | 1266 | 12 | 151.0 | 1400 | 180 | 1200 |
