JZH SeriesUltra-fine Grinding Ring MillWorking Principle: The grinding ring is drum-shaped (wheel type), and the grinding track is ring-groove shaped. Due to the friction between the material being ground and the grinding ring, the grinding ring rotates around its axis during operation to achieve crushing. The air introduced through the annular air inlet around the grinding disc lifts the material to the top turbo classifier for classification. Coarse particles fall back onto the grinding disc for further grinding, while fine powder is discharged through the outlet into a dust collector for collection as the finished product.

Performance characteristics of Sichuan Juzi ultrafine pulverizer:

1. Advanced grinding and classification technologies are integrated, offering the advantages of high fineness, large output, and low energy consumption.

2. The equipment has no bearings and requires no lubricating grease. Its particle size range is finer than that of ordinary mechanical mills, and it can produce products with a steep particle size distribution curve. The product fineness is adjustable within the range of d97=3–25.

3. Products that meet the particle size requirements are immediately classified and removed, avoiding over-grinding, which can improve grinding efficiency by approximately 30%.

4. The equipment is equipped with a high-efficiency and high-precision vertical turbo classifier and a high-efficiency pulse bag-type integrated system, operating under fully enclosed negative pressure with no dust pollution.

5. It has a flake shaping function, making it more effective for materials with strict flake requirements.

6. The complete set of equipment is easy to install and can be put into production immediately after installation. The equipment operates stably and reliably, ensuring normal continuous production. The product has high fineness classification accuracy, and product quality is guaranteed.

7. Widely used for deep processing and pulverization of non-metallic minerals and lightweight materials with a Mohs hardness below level 5, such as ultrafine grinding of ground calcium carbonate (marble, dolomite, calcite, and limestone), barite, kaolin, bentonite, illite, talc, pyrophyllite, mica, wollastonite, vermiculite, sepiolite, attapulgite, carbon black, graphite, diatomite, celestite, gypsum, fluorite, etc.

Sichuan Juzi's JZH series ultra-fine crushing ring mill has been widely used in the production and processing of industries such as metal silicon, quartz, alloy materials, magnetic materials, and non-metallic minerals.
