Fluidized Bed Jet Mill for Ultrafine Powder of Quartz Sand and Silica Micro Powder

Quartz particles processed from crushed quartz stone.

Quartz sand isQuartz stoneQuartz particles produced through crushing and processing. Quartz stone is a non-metallic mineral material that is hard, wear-resistant, and chemically stable.SilicateMineral. The color of quartz sand is milky white or colorless and translucent.Mohs hardness7。

Quartz sand is an important industrial mineral raw material and is not a chemical hazardous substance. It is widely used in glass, casting, ceramics, andFireproof materialsSmeltingFerrosiliconMetallurgical fluxes, metallurgy, construction, chemical industry, plastics,RubberAbrasives, filter media, and other industries.

Main Categories

Quartz has a relatively highFire resistance performanceIn industry, quartz sand is often classified into: ordinary quartz sand,Refined quartz sandHigh-purity quartz sand, fused quartz sand, and silica powder, among others.

Silica fume: Appearance is a gray or gray-white powder, with a refractoriness >1600°C. Bulk density: 200–250 kg/m³. The chemical composition of silica fume is shown in the table below:

The jet mill uses supersonic airflow for pulverization. This model incorporates the fluid dynamics developed by the Aerodynamics Research Institute.By learning numerical simulation software, the optimal flow field and ideal pressure distribution can be calculated to guide the design, greatly improvingIncreased crushing efficiency, reduced energy consumption, and minimal over-crushing. This equipment has the following features:

Equipment Features:

1. This equipment adopts **jet flow technology**, which results in **30% lower energy consumption** compared to domestic models of the same type, while achieving higher output.30% off.

2. After ultra-fine grinding, the finished product is directly obtained without the need for further sieving.

3. Equipped with an airflow regulating valve and a分级 impeller stepless speed controller, the product's particle size can be adjusted without stopping the machine, andThe fine powder can be fully recovered without polluting the environment.

4. Unique flow field design and constant gas-solid concentration control ensure a short residence time of materials in the chamber, preventing materialMaterial adhesion.

5. Increase the filtration area of the dust collector and use waterproof, oil-resistant, and anti-static membrane-coated filter bags to effectively prevent dust accumulation on the filter bags.Adhesion on;6. It adopts a vertical turbine classification device, featuring high rotational speed, wear resistance, and low system power configuration.

7. It can be used in series with grinding equipment such as ball mills, vibration mills, and Raymond mills to form a closed-circuit cycle.

8. The control system can adopt PLC program control, with real-time display of operating status, easy operation, and one-key start/stop functionality.

9. The system operates under negative pressure, with dust emissions not exceeding 10 mg/m³.

10. Ensure product precision, with no large particles present under electron microscope scanning, and maintain a strong classification effect for ultra-fine powders.

About Us

[Sichuan Zhongjin Powder Equipment Co., Ltd.] is located in Mianyang, China's Science and Technology City. Leveraging the civilian technology achievements of the Asia's wind tunnel cluster—the China Aerodynamics Research and Development Center, the company integrates aerodynamics, materials science, and mechanical manufacturing, and is dedicated to the research, development, manufacturing, sales, and service of ultra-fine grinding and classification equipment.

The company possesses core R&D technologies for domestic and international ultrafine grinding and classification equipment; technologies for fully utilizing jet energy; efficient classification and strict over-grinding control technologies; reliable sealing and leak-proof technologies; large particle control technologies; complete, stable, and smooth system design technologies; constant gas-solid concentration ratio technology within the grinding chamber; ultrafine powder collection, dust removal, and flue gas treatment technologies; and ultrafine grinding particle morphology control technologies, among others.

Our company specializes in the production of ultra-fine jet mills, air classifiers, classified impact mills, inert gas protection crushing and classification equipment, sodium bicarbonate desulfurization grinders, dust collectors, horizontal disc mills, steam kinetic energy mills, shaping machines, pneumatic conveying systems, vacuum feeders, and color material-specific crushing and classification machines, as well as supporting production lines for ultra-fine powder equipment. The equipment is suitable for ultra-fine crushing of materials in industries such as chemical materials, battery materials, non-metallic minerals, pharmaceuticals and food, metal powders, new materials, superhard materials, and ceramic building materials. The entire process operates under negative pressure, ensuring environmental friendliness, with particle sizes adjustable directly between 0.2-75μm. For inquiries, please call 13035677792.

Our company has various large, medium, and small-scale trial production machines. We welcome material processing and experiments!

Regarding after-sales service

1. Professional technicians provide on-site guidance for installation and commissioning, and train operators.

2. Conduct regular follow-up visits, provide technical consultation and spare parts, and jointly resolve issues that arise during production.

3. Meanwhile, the Technical Service Department promptly relays technical information and user feedback regarding equipment in use to the production and design departments, integrating this into all stages of development, design, and production to continuously provide users with better equipment.

4. When customers encounter issues, our company provides an immediate response during working hours and gives a reply within 2 hours. For problems that cannot be resolved via phone or fax, we will dispatch personnel to the site within 48 hours for domestic users.

5. Provide year-round technical consultation and lifelong preferential spare parts.
