360-degree rotating planetary ball mill

价  格
12000.00
品牌:
创未来
型号:
PM-4(F)
Degree of crushing:
Ultra-fine grinding
Energy consumption per unit:
The specific value is subject to actual energy consumption.
Output:
0.001(t/h)
Installed Power (kW):
0.75(KW)
Product fineness:
0.0001(mm)
Feed particle size (mm):
≤ 10(mm)
Working principle:
Media grinding
湖南创未来机电设备制造有限公司
店主:邓经理
地址:湖南省岳阳市平江县伍市镇华文路伍市工业园
  • 产品介绍

360° rotationPlanetary Ball MillBased on the vertical planetary ball mill, it adds a planetary disk flipping function. While the planetary disk and grinding jars perform planetary motion, they can also undergo 360° tilting and flipping within a three-dimensional space, enabling multi-dimensional and multi-directional movement of the grinding jars. This enhances the degree of disordered motion of the grinding balls and materials, allowing the entire material to be ground from multiple directions within the jar. As a result, the ground material becomes more uniform and finer, while also addressing issues such as material settling at the bottom and sticking to the jar.
