I. Introduction to Toothed Roll Crusher

The toothed roll crusher is a new product independently designed and developed based on the structural principles of the American Gundlach crusher.
The toothed roll crusher is composed of a transmission device, a frame part, crushing rolls, a mechanical spring device, and a linkage mechanism. Toothed roll crushers are divided into two major series: double-toothed roll crushers and four-toothed roll crushers.

II. Application of Toothed Roll Crusher

The tooth-roll crusher is mainly suitable for industries such as coal, metallurgy, mining, chemical, and building materials, and is particularly applicable for crushing raw coal (including gangue) in large coal mines or coal preparation plants.

III. Working Principle of the Toothed Roll Crusher

The tooth-roll crusher primarily utilizes specially designed wear-resistant tooth rolls rotating at high speed to split and crush materials, forming a mechanism that achieves high productivity.

IV. Characteristics of the Toothed Roll Crusher

1. The toothed roll crusher has a large crushing capacity.
2. Prevents power overload, overload protection, safe and reliable.
3. The distance between the toothed rollers is adjustable, and the bearings of the toothed rollers are centrally lubricated.
4. Optimized tooth profile design, selection of tensile and shear forces for crushing, high efficiency and low consumption, uniform particle output.
The 5-tooth roller crusher has the advantages of small size, large crushing ratio, low noise, simple structure, and convenient maintenance.

V. Image of a toothed roll crusher
