Wide range of applications
The MBD series diamond micropowder products are gray or beige in color and are classified into three grades—A, B, and C—based on their strength from high to low. Grade A diamond is of high quality and suitable for high-strength grinding; Grade B diamond has moderate quality and hardness, making it suitable for various common loose or bonded abrasives; Grade C diamond has low quality and hardness, offering a cost-effective micropowder option.
Good self-sharpening property
Due to the special manufacturing process, the color of the RVD series diamond is generally green, transitioning from dark green to gray as the particle size decreases from large to small. This product exhibits excellent self-sharpening properties and can be widely used in various resin-bonded diamond tools.
MBD-A Series MBD-A 2-4 Product Features:The product color ranges from gray to white, with a blocky crystalline structure, concentrated particle size distribution, and high-strength micropowder. Suggested applications:Cutting and polishing of high-hardness materials such as cemented carbide, gemstones, ceramics, silicon carbide, and optical glass. MBD-B Series MBD-B 6-10 Product Features:The product color ranges from gray to white, with a blocky crystalline structure, concentrated particle size distribution, and medium-to-high strength micropowder. Suggested applications:Used for grinding and polishing materials such as cemented carbide, ceramics, gemstones, silicon carbide, and optical glass. MBD-C Series MBD-C 4-8 Product Features:The product color ranges from yellow-green to white, with a blocky crystalline form, concentrated particle size distribution, moderate strength, and is an economical and practical type. Suggested applications:Used for grinding and polishing materials such as ceramics, synthetic gemstones, silicon carbide, and optical glass. RVD Series RVD 20-40 Product Features:The product color ranges from gray to gray-green, with ** self-sharpening properties. Suggested applications:Used for polishing glass, metal ceramics, industrial ceramics, stone, and other materials.Introduction to the MBD Series Micropowder
Basic Parameters
| Particle size | D 40-60 | D 20-40 | D10-20 | D 6-10 | D 5-9 | D 4-8 | D 2-4 | D 1-3 | D 0-2 | D 0.5-1 |
| D50 (µm) | 46±3 | 28±3 | 15±2 | 8.4±0.5 | 7.4±0.4 | 4.9±0.4 | 3.0±0.3 | 1.6±0.2 | 1.1±0.2 | 0.7±0.1 |
