Product Introduction
The laboratory vacuum disperser is a small-scale dispersion and foam mixing equipment produced by our company to meet the needs of universities, research institutions, and factory laboratories. The vacuum disperser features a digital speed display and stepless speed regulation, allowing for long-term operation with stable performance and low noise. The mixing disc is easy to disassemble, and the lifting structure is simple and user-friendly, making it an ideal experimental dispersion and defoaming device for laboratories.

Product Features

High dispersion efficiency and excellent product quality.

The equipment can reach a **rotation speed of up to 3000 rpm** and a **linear speed of up to 33 m/s** (recommended linear speed under normal conditions: 20-25 m/s), enabling rapid and uniform dispersion of materials into the liquid. Due to the extremely high shear force, the materials are evenly dispersed, achieving excellent suspension effects. It is equipped with a double-end mechanical seal structure, providing effective vacuum sealing and defoaming performance.

Easy to operate and safe.

The equipment features electric lifting, operates with low noise, and can quickly raise, lower, and secure the sealed drum. The dispersion disc is fixed to the main shaft with hexagon socket bolts, allowing for convenient and rapid disassembly, replacement, and easy cleaning. It is equipped with a locking seal strip mechanism that can quickly secure the sealed drum in place.

Small temperature rise

The ingredient mixing tank can be selected with a double-layer cooling jacket, allowing water cooling during operation to achieve excellent cooling effects, with a temperature rise of less than 10°.

The laboratory vacuum disperser utilizes the high-speed rotation of the dispersion disc to create a circular flow of the material, generating a strong vortex that spirals downward to the bottom of the vortex. Intense shear, impact, and friction occur between particles, achieving rapid dispersion, dissolution, and uniform mixing. An optional vacuum pump device is used to control the vacuum inside the tank.

Product Details

Material Viscosity: ≤25,000 cps

Production Capacity: 20-40L

Application Areas: Suitable for the dispersion and mixing of product materials in industries such as biology, pharmaceuticals, food, coatings, inks, adhesives, dyes, and pesticides.

Applicable Materials: Various non-flammable and non-explosive slurries with a viscosity below 25,000 cps and a solid content below 60%; such as: latex paint, industrial paint, water-based ink, etc.
