Product Introduction
The electric lifting disperser is a small-scale dispersion and mixing equipment produced by our company to meet the needs of universities, research institutions, and factory laboratories. The laboratory disperser comes with

Digital display of rotation speed, with variable frequency stepless speed regulation, allowing for long-term operation with stable performance and low noise. The stirring disc is easy to disassemble and replace, and the lifting structure operates with zero noise.

Electric lifting is an ideal experimental equipment for laboratories and pilot-scale testing.

Product Features

High dispersion efficiency and excellent product quality.

The equipment **can reach a rotational speed of 3000 rpm**, with a linear speed of up to 33 m/s (recommended linear speed under normal conditions: 20-25 m/s), enabling rapid and uniform dispersion of powder materials into

Inside the liquid material, the material is subjected to extremely high shear forces, resulting in uniform dispersion and excellent suspension effects.

Easy to operate and safe.

The equipment is equipped with a fully stainless steel electric lifting mechanism, enabling rapid lifting and secure fixation; the dispersion disc is fixed to the main shaft using hexagon socket bolts, allowing for convenient and quick disassembly.

Easy to replace and clean; equipped with a barrel clamping device that can quickly secure the mixing barrel, preventing displacement during operation and avoiding safety accidents.

Small temperature rise

The ingredient mixing tank is equipped with a double-layer cooling jacket. During operation, water is circulated for cooling, achieving an excellent cooling effect with a temperature rise of less than 10°C.

The electric lifting disperser uses the high-speed rotation of the dispersion disc to create a circular flow of the material, generating a strong vortex that descends in a spiral pattern to the bottom of the vortex. Particles interact with each other, producing

Intense shearing impact and friction achieve rapid dispersion, dissolution, uniform mixing, and simple emulsification.

Material Viscosity: ≤25000cps

Production Capacity: 5L-25L

Applicable Materials: Various non-flammable and non-explosive slurries with a viscosity below 25,000 cps and a solid content below 60%, such as latex paint, industrial paint, water-based ink, etc.

Application Areas: Suitable for dispersing and mixing product materials in industries such as biology, pharmaceuticals, food, coatings, inks, adhesives, dyes, and pesticides.

Product Details
