Product Introduction
The high-speed disperser features dispersion and mixing functions and is designed for large-scale batch operations. The equipment is equipped with a frequency converter for stepless speed regulation, allowing for long-duration operation with stable performance and low noise. The mixing disc is easy to disassemble, enabling the replacement of dispersing discs of different specifications and types based on process characteristics. The lifting mechanism uses a hydraulic cylinder as the actuator, ensuring stable lifting, and is equipped with an integrated oil tank that is environmentally friendly and leak-free. This product is an **ideal device** for solid-liquid dispersion and mixing.

Product Features

High dispersion efficiency and excellent product quality.

The equipment's **rotational speed can reach 2930 rpm (high power** 1450 rpm), with a linear velocity of over 20 m/s, enabling rapid and uniform dispersion of powder into liquid materials. Due to the extremely high shear forces, the materials are evenly dispersed, resulting in excellent suspension effects.

Easy to operate and safe.

The equipment uses an oil cylinder as the lifting actuator, with a control valve to manage the disperser's ascent, stop, and descent, offering simple operation and high stability. The dispersion disc is secured to the main shaft with hex socket bolts, allowing for convenient and quick disassembly, replacement, and easy cleaning. Different dispersion discs can be swapped based on process requirements to achieve optimal dispersion results. It features various clamping methods (belt, manual, pneumatic) to quickly secure the mixing drum, preventing displacement during operation and ensuring safety.

Diverse methods

The equipment has a compact structure and can be designed as floor-standing or platform-mounted, with the cylinder body optionally configured as either movable or fixed.

The non-standard nature is strong.

Customizable various types of non-standard products, such as explosion-proof type, sealed type, with lifting cover type, coaxial/dual-shaft composite type, multi-cylinder single-machine type, kettle type, etc. Materials can be customized according to requirements.

The high-speed disperser operates with the dispersing disc rotating at high speed, causing the material to form a circular flow and generate a strong vortex, which descends in a spiral pattern to the bottom of the vortex. Intense shear, impact, and friction occur between particles, achieving rapid dispersion, dissolution, uniform mixing, and emulsification. The hydraulic pump drives the hydraulic plunger to lift and lower, thereby moving the entire transmission mechanism and working group.
