Product Introduction
The hand-cranked lifting variable-frequency disperser is a new product designed based on practical needs, primarily used for pilot-scale experiments in the pre-production stage of liquid slurries such as paints, coatings, pigments, plastics, and food products. It provides accurate data for large-scale production and can also be used for small-batch production. This equipment can disperse volumes ranging from 5L to 50L.

Product Features

1. Variable frequency speed control motor

2. Solid Stainless Steel Dispersion Shaft

3. Energy-saving manual lifting

4. Safety clamp for material barrel

5. Removable fixed casters

The serrated circular dispersion disc of the disperser operates at high speed within the container to complete the processes of solid-liquid dispersion, wetting, deagglomeration, and stabilization. This causes the slurry to form a rolling annular flow, generating a strong vortex, with particles on the slurry surface spiraling downward to the bottom of the vortex. A turbulent zone forms 2.5-5mm from the edge of the dispersion disc, where the slurry and particles undergo intense shear and impact. Outside this zone, two streams form above and below, ensuring thorough circulation and turnover of the slurry. Below the dispersion disc of the disperser, a laminar flow state occurs, where slurry layers at different velocities diffuse into each other, achieving the dispersion effect.

Product Details
