The pin-type bead mill is a continuous-operation, closed wet grinding equipment. It features simple operation, good reliability, and a complete range of specifications, making it one of the most widely used wet grinding devices on the market, with highly mature performance and structure. The sealing system adopts a double-end mechanical seal, equipped with a cooling system for the double-end mechanical seal, ensuring reliability and durability. It includes temperature and pressure monitoring and protection to guarantee product quality. The use of zirconia beads offers advantages such as high grinding efficiency, excellent fineness, wide application range, and good wear resistance.

Product Features

Low energy consumption ratio, high cost performance.

The equipment drive uses a motor to transmit power to the main shaft through large and small pulleys, making startup easy. The stirring rod is made of a specially designed zirconia structure, which ensures high efficiency while consuming less electricity. It is a cost-effective product among grinding equipment.

Easy to operate and clean.

The equipment features an on-site operation box integrated with the frame for convenient operation. It is equipped with a bead collection hopper, and the grinding chamber is designed for easy disassembly from the frame. A pulley mechanism allows the cylinder to be detached, effectively enabling thorough cleaning of the chamber and zirconium beads. This design is suitable for processing materials of different colors and varieties.

Safety monitoring, product stability.

The grinding chamber is equipped with a special cooling water jacket, which allows water to flow through for cooling during operation, achieving excellent cooling effects with a typical temperature rise of less than 10°C. The equipment features temperature and pressure monitoring, allowing the setting of "protection values" to ensure product quality.

Complete specifications, customizable for non-standard requirements.

Equipment specifications range from 10L to 100L, covering a full range of sizes; explosion-proof models can be customized for non-standard requirements.

The diaphragm pump of the pin-type bead mill circulates the material between the material tank and the grinding chamber. The high-fill-rate grinding media in the chamber is driven by the rotation of the disc, generating forces in various directions and irregular motion. The particles in the material are continuously collided and rubbed by the grinding media. Meanwhile, the screen separates the material from the grinding media, allowing the material to continuously circulate from the material tank to the grinding chamber. This achieves the goal of reducing particle size and narrowing the particle size distribution range.

Material Viscosity: ≤20,000 cps

Production Capacity: 20-2000L

Application: Suitable for the dispersion and grinding of product materials in industries such as biology, medicine, cosmetics, food, coatings, inks, color pastes, dyes, and pesticides.

Applicable Materials: Materials with a viscosity below 20,000 cps and requiring high grinding fineness; such as latex paint, industrial paint, color paste, water-based ink, pesticide suspension concentrate, lithium battery slurry, and thousands of other materials.
