The pneumatic lifting basket mill integrates dispersion and grinding, making it suitable for wet grinding of low to medium viscosity fluids. It is widely used in public institutions, research organizations, universities, and colleges for small-batch production. The equipment features a frequency converter for stepless speed regulation, enabling long-duration operation with stable performance and low noise. The grinding basket has a well-designed structure, making it easy to disassemble and clean. The lifting mechanism uses a pneumatic cylinder as the actuator, which is environmentally friendly and pollution-free, making it an ideal grinding device for small-batch production.

Product Features

High grinding efficiency, good product fineness.

The equipment can reach a speed of **2800 rpm**, and its powerful kinetic energy drives the zirconia stirring rod to cause irregular movement of the grinding media in the chamber. The media collide and rub against each other at high speed, rapidly reducing the particle size of the powder, resulting in excellent grinding fineness.

Easy to operate and safe.

The equipment uses a cylinder as the lifting actuator, with a pneumatic control valve to manage the grinding device's ascent, stop, and descent. It features low air consumption and simple operation. Equipped with a manual barrel clamping device, it can quickly secure the grinding barrel, preventing displacement during operation and ensuring safety. The machine frame comes with casters, occupying minimal space and allowing for easy mobility.

Low temperature rise, stable product performance.

The ingredient tank is equipped with a double-layer cooling jacket, which allows water cooling during operation, ensuring excellent cooling performance with a typical temperature rise of less than 10°C. The grinding chamber can be customized with cooling.

The non-standard nature is strong.

Explosion-proof type available for non-standard customization; grinding chamber can be customized with zirconia material; equipment material can be customized with SS316L stainless steel.

The motor of the pneumatic lifting basket mill drives the stirring rod and the bottom dispersion disc to rotate at high speed, creating a vacuum in the upper part of the dispersion disc and inside the basket cavity, causing the slurry to be drawn into the basket grinding chamber. The stirring rod drives the grinding media within the chamber to generate forces in all directions, causing the particles in the material to undergo continuous collision and friction, resulting in a reduction in particle size and a narrower particle size range. The high-speed rotation of the dispersion disc generates a vortex that draws the material out of the chamber and recirculates it back to the feed inlet, achieving a highly significant dispersion and mixing effect. The cylinder is controlled by rotating a pneumatic valve or using solenoid valve jog control, enabling the cylinder to lift and lower, thereby driving the motor and the working head to move up and down.

Material Viscosity: ≤5000cps

Production capacity: 20-200L

Application: Suitable for the dispersion and grinding of product materials in industries such as biology, pharmaceuticals, cosmetics, food, coatings, inks, color pastes, dyes, and pesticides.

Applicable materials: Materials with a viscosity below 5000cps and high fineness requirements for grinding, such as latex paint, industrial paint, color paste, water-based ink, pesticides, suspensions, ceramic glazes, and thousands of other materials.
