Product Introduction
The paste filling machine for small batches, suitable for both paste and liquid, uses the volumetric method to calculate and control the filling volume by adjusting the plunger's capacity. Through the reciprocating motion of the piston, it achieves rapid filling. This equipment offers the advantages of high filling efficiency and easy maintenance. It is widely used in industries such as coatings, inks, paints, asphalt, adhesives, lubricating oils, petrochemicals, and fine chemicals, making it suitable for filling fluids with high, medium, and low viscosity.

Product Features

Fast filling speed, wide range of applications.

The filling head can be either single or dual, operating with a piston mechanism for high-speed filling, cost savings, and reduced worker workload. It is suitable for filling round, square, flat, and various other bottle shapes and diameters. The unique valve body design enables it to handle pastes, gels, and liquids.

Easy to operate and maintain.

Operated by a foot switch, it is convenient and practical. The filling volume is easy to adjust, and disassembly, cleaning, and reassembly are quick and convenient. It can be operated by one person. Equipped with all imported components, the quality is stable and reliable.

High filling accuracy

The metering structure adopts a plunger method, ensuring precise filling with a metering error of less than ±1%.

Excellent environmental performance and safety.

Fully pneumatic control, meeting explosion-proof requirements.

The paste filling machine operates as follows: the inlet valve opens, the outlet valve closes, and the piston rod retracts, drawing the material from the temporary storage hopper into the piston chamber. Then, the inlet valve closes, the outlet valve opens, and the piston rod advances, pushing the material from the piston chamber into the filling container. This process repeats cyclically.

Material Viscosity: ≤100,000 cps

Production Capacity: 5-1,000 ml

Application areas: Suitable for filling paints, coatings, inks, adhesives, curing agents, organic solvents, daily chemicals, detergents, pesticides, pharmaceuticals, lubricating oils, edible oils, and various flowable liquids.

Applicable Materials: Liquid and slurry materials with a viscosity below 100,000 cps and fluidity, such as cooking oil, latex paint, color paste, industrial paint, curing agents, organic solvents, water-based ink, pesticide suspensions, adhesives, detergents, and thousands of other materials.

Product Details
