Ultra-fine jet mill specially designed for easily adhesive materials such as cosmetics and pigments

Device Overview:

ZJThe series of air jet mills specifically designed for pigment materials is developed by our company based on the grinding requirements of pigments, which include narrow particle size distribution, minimal increase in impurities, and good dispersibility. It also takes into account the characteristics of pigment materials, such as high viscosity, poor fluidity, fine particle size, and a tendency to adhere to walls.
This machine can use ordinary compressed air as the crushing medium, or it can use superheated steam as the crushing medium. Crushing under high temperature conditions can improve the dispersion of pigments and enhance their fluidity. It has low energy consumption, only 1/3 to 2/3 of that of compressed air.

Process principle and characteristics:

Structure of the Colorant-Specific Jet Mill: Mainly composed of a crushing chamber, nozzle opening, discharge outlet, airflow outlet, compressed air inlet, etc.

Working Principle: The material is fed quantitatively through a feeding device and transported into the crushing chamber using compressed air (or superheated steam) as the carrier. Upon entering the crushing chamber, the material is driven by a specific supersonic airflow, forming a regular flow pattern. This causes mutual impact and shearing between material particles, as well as collision and friction with the chamber walls, upper cover, and lower cover, achieving the purpose of crushing. During the crushing process, particles of different fineness generate varying centrifugal forces in the rotating airflow. Coarse particles, due to their greater centrifugal force compared to the centripetal airflow force, are thrown to the periphery and continue the crushing process. Particles of the required fineness, driven by the centripetal airflow force, are carried by the exhaust airflow to the discharge outlet. They are then transported through pipelines directly into a collector. After the finished product is collected, the purified air is discharged into the atmosphere.

Performance Features:

1) Suitable for ultra-fine grinding of brittle materials (generally with moisture content less than 5%), the high impact velocity makes it easy to obtain particles of several micrometers.

2) Since the crushing mechanism primarily relies on autogenous grinding through interactions between powder particles, the product is less prone to contamination by other substances, enabling the production of high-purity ultrafine powders.

3) Based on the properties of different materials, corresponding lining materials can be selected (mainly around the crushing chamber and the inlet/outlet pipes) to address issues caused by hard materials (with a Mohs hardness not exceeding 9) and sticky materials during the crushing process.

4The special inlay structure with ultra-hard wear-resistant material lining greatly extends the service life of the jet mill.

5) High product fineness: d90 = 0.3~10 μm, with a narrow particle size distribution and no large particles.

6) High grinding efficiency and low energy consumption, saving 30% energy compared to other types of jet mills.

7The lining inside the crushing chamber is made of ultra-wear-resistant and impact-resistant materials, utilizing a special embedded buffering structure to effectively overcome the issue of the wear-resistant material being prone to cracking, thereby ensuring its service life.

8) Simple structure, no moving parts;

9) The entire crushing process is sealed, with no dust flying.

10Low noise, no vibration;

11Easy to disassemble and clean; no prior knowledge required.

12) It enables high-volume continuous production with a high degree of automation.

Application Areas:

Crushing of sticky materials such as cosmetics, pigments, titanium dioxide, and flame retardants.

Technical Parameters:

Note: General materials use compressed air as the working medium, while special materials require superheated steam as the working medium (medium temperature).

About Us

[Sichuan Zhongjin Powder Equipment Co., Ltd.] is located in the Science and Technology City of China.—Mianyang, the company relies on the Asian Wind Tunnel Cluster.—The civil technology achievements of the China Aerodynamics Research and Development Center integrate aerodynamics, materials science, and mechanical manufacturing, dedicated to the research, development, manufacturing, sales, and service of ultra-fine grinding and classification equipment.

The company possesses core R&D technologies for domestic and international ultrafine grinding and classification equipment; technologies for fully utilizing jet energy; efficient classification and strict over-grinding control technologies; reliable sealing and leak-proof technologies; large particle control technologies; complete, stable, and smooth system design technologies; constant gas-solid concentration ratio technology within the grinding chamber; ultrafine powder collection, dust removal, and flue gas treatment technologies; and ultrafine grinding particle morphology control technologies, among others.

Our company specializes in producingUltra-fine jet mills, air classifiers, classified impact mills, inert gas protection grinding and classifying equipment, sodium bicarbonate desulfurization mills, dust collectors, horizontal disc mills, steam kinetic energy mills, shaping machines, pneumatic conveying systems, vacuum feeders, colorant-specific grinding and classifying machines, and other ultra-fine powder equipment and supporting production lines.The equipment is suitable for ultra-fine grinding of materials in industries such as chemical materials, battery materials, non-metallic minerals, pharmaceuticals and food, metal powders, new materials, superhard materials, and ceramic building materials. The entire production process operates under negative pressure, ensuring environmental friendliness, and the particle size can be adjusted within0.2-75μmDirectly adjustable. Feel free to call for consultation.13035677796

Our company is equipped with various large, medium, and small-scale trial production machines. We welcome material processing and experiments!

Regarding after-sales service

1Professional technical personnel provide on-site guidance for installation and commissioning, and train operators.

2Regular follow-up visits, provision of technical consultation and spare parts, and joint resolution of issues arising during production.

3Meanwhile, the Technical Service Department promptly feeds back technical information and user feedback regarding equipment in use to the production and design departments, integrating this into all stages of development, design, and production to continuously provide users with better equipment.

4When customers encounter issues, our company responds promptly during working hours and provides a reply within 2 hours. For problems that cannot be resolved via phone or fax, we will dispatch personnel to the site within 48 hours for domestic users.

5We provide year-round technical consultation and lifelong preferential spare parts.
