The 300mL laboratory internal mixer is made entirely of alloy materials, requiring no spraying or electroplating, ensuring a sturdy and wear-resistant mixing chamber. It is suitable for stirring, dispersing, and mixing metal powders, ceramic powders, binders, and other formulations at a specific temperature. After the materials form a paste-like consistency, they are discharged after a set time for the next process. It is an ideal **mixing equipment** for laboratories, school teaching, and sample preparation.

·Working Principle

Inside the internal mixer, two rotors rotate relative to each other at a certain speed ratio, clamping the material from the feeding port and bringing it into the roll gap, where it is subjected to extrusion and shearing by the rotors. After passing through the roll gap, the material hits the "W"-shaped sharp edge of the mixing chamber and is divided into two parts.

, respectively, along the gap between the front and rear chamber walls and the rotor, then return to the top of the rotor. The material undergoes intense shearing and mixing inside the closed internal mixer under specific pressure and temperature conditions, ensuring the formulation materials are fully dispersed.

Plasticization, thereby allowing the formula to take **effect**.

·Product Features

(1) Super alloy inner liner, newly upgraded;

(2) The mixing chamber can be fully opened, allowing for thorough cleaning of materials without any dead corners;

(3) Excellent powder leakage prevention technology;

(4) Through-type heating system; (5) Precise temperature control;

(6) The equipment occupies a small footprint and is simple and convenient to operate and maintain.
