Dust Removal Turbo MillStructure and Working Principle：Dust Removal Turbo MillIt is mainly composed of components such as the casing, door, turbine, main shaft, screen, pulley, and electric motor.
Dust Removal Turbo MillDuring operation, the motor drives the spindle and turbine to rotate at high speed. The turbine and the grinding blocks on the screen ring form a crushing and grinding pair. When the material enters the machine cavity from the feed hopper, it undergoes intense friction and strong impact against the inner side of the turbine blades within the rotating airflow generated by the turbine, and is further ground in the gaps between the blades and the grinding blocks. While crushing the material, the turbine draws in a large amount of air, which serves to cool the machine, grind the material, and transport fine particles. The fineness of the crushed material depends on the nature of the material, the size of the screen mesh, and the throughput of the material and air.
Turbo Dust Removal CrusherThe bearing components are equipped with specially designed labyrinth seals, which effectively prevent dust from entering the bearing chamber, thereby extending the service life of the bearings. The machine door is fitted with a silicone rubber sealing ring, ensuring no dust leakage that could contaminate the operating environment.
Dust Removal Turbo MillCharacteristics：
1. Strong crushing capability, low energy consumption, and relatively fine product particle size.
2. Large crushing space: The high-intensity wind pressure generated during turbine operation not only enhances production capacity and reduces over-crushing, but also effectively prevents material deposition and clogging of the screen during the crushing process.
3. Due to enhanced shearing, its crushing capability for fibrous materials is higher than that of ordinary equipment.
4. The screen mesh is easy to install and reliably positioned, all using a plug-in design. Its service life is significantly longer compared to the ring screen type.
5. Design a built-in motor to lower the machine's center of gravity, effectively reducing equipment noise.
