In recent years, driven by China's energy conservation and emission reduction policies along with proactive fiscal measures, urban wastewater treatment has developed rapidly, and significant progress has been made in water environment management. However, the sludge generated in large quantities during wastewater treatment has an excessively high moisture content, exceeding 80%, making it unsuitable for direct sanitary landfill or other final disposal methods. The daily accumulation of sludge with no viable outlet has severely impacted the normal operation of wastewater treatment plants, caused significant harm to the environment, and seriously hindered the implementation of China's energy conservation and emission reduction strategic policies.

Our company has introduced advanced foreign sludge drying technology and, based on domestic conditions, developed a specialized municipal sludge dryer that fully meets industry customer requirements, earning the trust and collaboration of an increasing number of enterprises. The new municipal sludge paddle dryer produced by Haomai Drying is a conduction-heated, low-speed stirring dryer. It features a jacket on the dryer body and hollow paddles on the hollow shaft, through which a heat carrier is circulated. Under the agitation of the stirring paddles, the wet material undergoes thorough heat exchange with the heated surfaces of the drum and paddles, achieving the drying objective. Currently, our company has collaborated with numerous large, medium, and small enterprises domestically, resolving technical challenges in sludge treatment for our clients.

Structural Principle of Sludge Dewatering and Drying Equipment for Municipal Wastewater Treatment
The equipment adopts a conduction heating method, consisting of two intermeshing blade shafts, a W-shaped housing base with a jacket, and a transmission part. The entire drying process of the sludge is carried out in a sealed state, where volatile organic compound odors and moisture are sent to the exhaust gas treatment device via an induced draft system in a closed environment, thereby avoiding environmental pollution. The heating medium is typically steam or thermal oil. The heating medium is divided into two paths, entering the jacket of the dryer housing and the inner cavity of the blades respectively, heating both the machine cavity and the blade shafts simultaneously, and drying the sludge through conduction heating. After the sludge enters the machine cavity, it is turned and stirred by the rotation of the blades, continuously renewing the heating interface and fully contacting the heated body and blades, thereby causing a large amount of moisture to evaporate from the sludge. At the same time, the sludge is conveyed toward the discharge outlet with the rotation of the blade shafts, and finally, the uniformly dried sludge is discharged through the outlet.

Application of Dewatering and Drying Equipment for Municipal Wastewater Treatment Sludge
The paddle dryer for municipal sludge launched by Haomai has been successfully applied in wastewater treatment at multiple domestic enterprises. Its heat transfer, cooling, and stirring characteristics enable it to perform the following unit operations: combustion (low temperature), cooling, drying (solvent recovery), heating (melting), reaction, and sterilization. The stirring paddles also serve as heat transfer surfaces, increasing the heat transfer area per unit effective volume and shortening processing time. The wedge-shaped paddle heat transfer surfaces also have a self-cleaning function. The compression-expansion stirring function ensures uniform mixing of materials.

The municipal sludge-specific dryer is suitable for drying various types of sludge, including papermaking sludge, printing and dyeing sludge, leather sludge, electroplating sludge, oilfield sludge, domestic sludge, petrochemical sludge, and activated sludge. If you have any needs or technical inquiries regarding sludge drying and treatment, please feel free to contact us. Our company will thoroughly resolve your sludge-related concerns. Consultation hotline:13906112721 Manager Zhang
