Principle:
After being heated and purified, the air is drawn in from the bottom by an induced draft fan and passes through the perforated plate of the hopper. Inside the working chamber, fluidization is achieved through stirring and negative pressure, causing moisture to evaporate rapidly and be carried away by the exhaust, thereby quickly drying the material.
Application:
● Granules produced by mechanical screw extrusion, oscillating granulation, and wet high-speed mixing granulation.
● Drying of wet granules and powdered materials in the fields of medicine, food, feed, chemical engineering, etc.
● Materials in the form of large particles, small lumps, or sticky clumps.
● Materials such as konjac and polyacrylamide, whose volume changes during drying.
Features:
● The fluidized bed has a circular structure to avoid dead corners.
● The hopper is equipped with a stirring mechanism to prevent the agglomeration of moist materials and the formation of channeling during drying.
● It adopts a tilting and dumping mechanism for convenient, rapid, and thorough unloading, and can also be designed with an automatic material loading and unloading system as required.
● Operates under sealed negative pressure, with gas filtered. Easy to operate and clean, it is an ideal piece of equipment that meets "GMP" requirements.
● Fast drying speed with uniform temperature; each batch typically takes 20–30 minutes to dry.
