Ultra-fine bead mill

Here is the English translation of "简介": **Introduction**

The material enters the grinding chamber from the top via the feed pump, is evenly distributed as the rotor rotates, and undergoes thorough pre-dispersion treatment under the action of eddy current centrifugal force within the gaps between the rotor and stator.

Working principle

The material follows the feed pump. Entering the grinding chamber from the top, the material is evenly distributed as the rotor rotates. Under the action of eddy current centrifugal force within the gaps between the rotor and stator, the material undergoes a thorough pre-dispersion process. In the subsequent intense grinding, the rotor and stator work together in a counter-grinding action. The grinding media continuously undergo intense impact changes, and the grinding media then act on the material, causing the material to be ground. The ground material remains in the grinding chamber for a specific grinding time, resulting in an extremely narrow product particle size distribution. During the feeding process, Under the action of pump pressure and centrifugal force, due to differences in density, the grinding media returns to the grinding chamber, while the material moves in the opposite direction of the centrifugal force, passing through a mesh-type separator for filtration and separation, in a continuous cycle. Special rotor structure design, quantity and volume, and installation position are designed according to vortex fluid dynamics to achieve a higher specific grinding energy, improve material grinding efficiency, and bring the material to the nanoscale. As measured by a third-party Malvern laser particle size analyzer, Fixed, *the minimum fineness can reach less than50nm。

Battery Industry: Lithium Iron Phosphate Battery Cathode Materials, etc.

Digital Consumables: Digital Inkjet Ink, etc.

Ceramic materials: aluminum oxide, zirconium oxide, silicon carbide, etc.

Mineral pigments: titanium dioxide, calcium carbonate, iron oxide, etc.

Rare earth materials: yttrium oxide, indium, cerium, etc.

Cosmetics category: pearl powder, etc.

The pharmaceutical preparation industry

Application Areas
