Hydraulic Lifting Coaxial Dispersion Mixer

Product Introduction

The hydraulic lifting coaxial dispersion mixer (vacuum type) is a functional product developed based on the standard hydraulic lifting high-speed disperser. The equipment is equipped with a sealed vacuum cover that matches the pull cylinder, and the vacuum cover method...

The slot milling inside the ring is equipped with a corrosion-resistant elastic sealing ring, ensuring no leakage under sealed vacuum conditions. It can be paired with a vacuum pump or pump set, achieving an ultimate vacuum level of -0.0998mpa（20mbar），

Suitable forDispersion and mixing under special working conditions such as "vacuum degassing," "vacuum feeding," and "inert gas protection."

Product Features:

1. Variable frequency speed regulation, easy to operate;

2. Hydraulic operating system for greater stability;

3. The sealed drum lid effectively prevents solvent evaporation; the sight glass and searchlight allow observation of the mixing status; the sanitary manhole enables cleaning and material addition.

4. It can be made into floor-standing or platform types, and the cylinder body can be designed as either movable or fixed.

5. Customizable explosion-proof type, coaxial/dual-axis composite type, multi-cylinder single-machine type, SS304/SS321/SS316, etc.

Working principle

The dispersion disc operates at high speed, causing the material to form a circular flow and generate a strong vortex, which spirals downward to the bottom of the vortex. Intense shearing, impact, and friction occur between particles, achieving rapid dispersion and dissolution.

The PTFE scraper rotates in close contact with the tank wall, scraping the wall surface. This resolves the issue of material adhesion to the wall while also accelerating material circulation. The hydraulic pump drives the hydraulic plunger to lift and lower, thereby driving the entire transmission system.

The motor mechanism and the working group are raised and lowered.

Technical Parameters
