Planetary Mixer

Product Introduction

Industrial-grade planetary mixingThe machine is a new type of high-performance, high-speed, easy-to-clean and maintain mixing equipment designed and manufactured by Yongyan. The dual-group agitators of this equipment rotate around the axis while revolving, and the form of the agitators is selected based on the viscosity of the material and the process characteristics. Common types include paddle, spiral, claw, and frame types, which provide good mixing, reaction, kneading, and dissolving functions. The high-speed disperser consists of multiple layers of serrated dispersion discs with extremely high linear velocity, and it also operates at high While rotating rapidly on its own axis, it also revolves around a central axis, enabling the rapid dispersion of powder materials (additives) into the slurry, providing a strong dispersing effect. The dual planetary mixer is equipped with a set of independent scrapers that continuously scrape the barrel wall. At the same time, The stirring blade can be equipped with a scraper to scrape the bottom of the material barrel, eliminating dead zones during stirring and ensuring product stability. Its transmission adopts planetary gear drive, providing high output torque, making it suitable for high-temperature, high-solid, high-viscosity, and other demanding conditions. Difficult working conditions; the equipment features a sealed design and can be used with a vacuum system to achieve vacuum mixing. The mixing tank can be designed with a jacketed heating system, and when used with a mold temperature controller, it enables constant temperature mixing. It is a solution on the market for dispersing high-viscosity materials. Mixing equipment.

Working principle

Industrial planetary mixer equipment consists of a geared motor, planetary carrier, agitator, disperser, wall scraper, material tank, and hydraulic lift. The system consists of a lowering system, a hydraulic extrusion system, and a frame. When the planetary carrier rotates, it drives the stirring shaft and dispersion shaft inside the box to revolve around the axis of the material barrel while simultaneously rotating at high speed on their own axes, thereby subjecting the material to intense shearing and kneading actions, achieving To achieve thorough dispersion and mixing; a wall scraper is mounted on the planetary frame and rotates with it, continuously scraping against the inner wall of the barrel. After the barrel wall undergoes precision machining on a large lathe, it is further polished using an automatic polishing machine to ensure that the movable scraper on the planetary frame rotates smoothly. When transferring, completely scrape off the material on the barrel wall to ensure no material remains. Additionally, scraper blades can be added to the mixing paddle to scrape the bottom of the barrel, preventing dead zones during mixing, ensuring product stability, and improving mixing efficiency.

Technical Parameters

Product Applications

Suitable for the dispersion, emulsification, and mixing of product materials in industries such as paint, coatings, putty, adhesives, ink, lithium battery slurry, and glue.
