Industrial-grade Basket Mill
Here is the English translation of "简介": **Introduction**
It changes the traditional separate grinding method by integrating the functions of dispersion and grinding into a single process. At the same time, it is easy to clean, leaves minimal residue, is economical and practical, and achieves good grinding fineness.
Product Details
It is especially suitable for industries with high fineness requirements, such as pigments, dyes, inks, ceramics, color pastes, coatings, pharmaceuticals, and cosmetics. Cleaning and color changing are both very convenient.
Product Features
1. This machine is suitable for products that require frequent color changes, with easy cleaning and minimal solvent usage during cleaning.
2. It adopts a hydraulic lifting method, which is stable and convenient. The structure is sturdy and durable.
3. Equipped with an imported frequency converter to achieve stepless speed regulation.
4. Non-standard technical parameters can be customized according to customer requirements.
Model | Drive power (kW) | Processing capacity (L) | Speed (rpm) | Grinding basket volume (L) | Amount of zirconium beads (KG) | Lifting stroke (mm) | Hydraulic power (kw) | Overall Dimensions (mm) |
YLM-1.5 | 1.5 | ≤30 | 0-1440 | 2.5 | 1.2 | 600 | 0.55 | 1500×1500×750 |
YLM-2.2 | 2.2 | ≤50 | 0-1440 | 2.5 | 2 | 800 | 0.55 | 1500×1500×750 |
YLM-4 | 4 | ≤100 | 0-1440 | 4 | 3 | 800 | 0.55 | 1500×1500×750 |
YLM-7.5 | 7.5 | ≤200 | 0-1440 | 5 | 6 | 800 | 0.75 | 1800×1700×750 |
YLM-11 | 11 | ≤250 | 0-1440 | 9 | 9 | 900 | 0.75 | 1800×1700×750 |
YLM-15 | 15 | ≤350 | 0-1440 | 10 | 11 | 900 | 0.75 | 1800×1700×750 |
YLM-18.5 | 18.5 | ≤500 | 0-1440 | 15 | 15 | 1100 | 1.1 | 2150×2000×900 |
YLM-22 | 22 | ≤800 | 0-1440 | 19 | 18 | 1100 | 1.1 | 2150×2000×900 |
YLM-30 | 30 | ≤1000 | 0-1440 | 27 | 28 | 1400 | 1.1 | 2700×2300×1100 |
YLM-37 | 37 | ≤1200 | 0-1440 | 32 | 30 | 1600 | 1.5 | 2700×2300×1100 |
YLM-45 | 45 | ≤1500 | 0-1440 | 50 | 40 | 1600 | 1.5 | 2700×2300×1100 |
YLM-55 | 55 | ≤2000 | 0-1440 | 60 | 50 | 1600 | 1.5 | 2700×2300×1100 |
