Intelligent Slag Removal and Filtration System

Product Introduction

The intelligent filtration and slag removal system includes a movable platform, a stainless steel scraper filter, a pneumatic diaphragm pump, a pneumatic dual-unit, a single-acting pneumatic control valve, and a slag removal assembly, etc., featuring an integrated filtration and slag removal function.

Product Features:

1. High filtration efficiency;

2. Consistent operations, ensuring continuous workflow;

3. Save labor;

4. The filtration accuracy range is optional;

5. Environmentally friendly, eliminating solid waste from filter bags and liquid waste from cleaning.

6. Optional multi-barrel high-flow efficient filtration, fully automatic electrical control system and PLC;

7. Simple structure, easy to disassemble and assemble, and easy to clean internally.

8. Safe, reliable, and stable operation;

9. Reduce production costs without consuming disposable consumables.

10. The filter residue can be used as a combustion energy source, offering value for secondary recycling.

Working principle

WhenThe material enters through the inlet, passes through a metal wedge-shaped filter screen with an ultra-large filtration area, where the qualified material is filtered out and pumped to the next step for product filling. The agitator, equipped with a scraper, rotates closely against the surface of the filter screen to scrape off impurities, which then move downward. Liquid enters the screw chamber. In the slag removal system, the screw rotates to extrude dry slag (the extruded slag is in a continuous solid state), and the extruded filtrate is pumped back to the feed inlet for cyclic filtration.
