Vacuum Homogenizer

Product Introduction

Non-standard Vacuum Homogenizer High performance, can be reasonably configured according to the customer's process, suitable for products that require emulsification and stirring under vacuum conditions. It can also be equipped with low-speed wall-scraping stirring for emulsifying and stirring high-viscosity products. Can be configured with an inline high-shear emulsifier. Used for processes such as dispersion, emulsification, homogenization, and mixing. It can be equipped with: a batching system, a discharge system, a cooling and heating temperature control system, a vacuum system, nitrogen protection,Online pH measurement and detection, CIP cleaning systems, etc. Wide application range with strong process controllability. Can be customized to sanitary grade, suitable for product production or pilot trials in industries such as pharmaceuticals, food, and cosmetics.

Working principle

Strong A powerful motor rotates at high speed to create a vacuum between the rotor and stator. Material is drawn in from the upper and lower parts of the rotor and stator. The central stirring mechanism in the upper interior, along with the PTFE scraper, continuously conforms to the wall of the mixing pot, scraping off any adhered material and ensuring it is removed. The materials being taken continuously generate new interfaces; the agitator, in coordination with the high linear speed shearing of the rotor and stator, causes the materials to undergo intense impact, crushing, centrifugation, liquid layer friction, and powerful shearing in the gap between the rotor and stator before being ejected outward. In the process of multiple Under the action of forces from different directions, a strong turbulent flow is generated; since the emulsifying pot is in a vacuum state, the bubbles generated during the stirring process of the materials are promptly removed.

Technical Parameters
