Product Introduction
The wall-scraping hydraulic disperser is a product developed based on the single-shaft disperser, featuring both dispersion and wall-scraping functions. During the dispersion process, the wall scraper rotates along the wall of the container, creating a certain radial stirring effect. At the same time, the PTFE scraper can scrape off materials adhering to the container wall, demonstrating excellent adaptability to medium-to-high viscosity and thixotropic materials. The final product is discharged cleanly, and the container is easy to clean.

Product Features

High dispersion efficiency

The wall-scraping disperser has a linear dispersion speed of over 20 m/s, enabling rapid and thorough dispersion of powder into liquid materials.

Easy to operate and safe.

The wall-mounted disperser uses an oil cylinder as the lifting actuator, with a control valve to manage the raising, stopping, and lowering of the disperser, offering simple operation and high stability. The dispersion disc is fixed to the main shaft with hexagon socket bolts, allowing for convenient and quick disassembly, replacement, and easy cleaning.

Clean discharge, easy maintenance.

The scraper design effectively resolves the issue of material adhesion to the wall. The scraper is designed to be adjustable, allowing it to closely conform to the drum body based on the material's reaction force, ensuring a long service life. Additionally, the bolt-type design facilitates easy replacement.

The non-standard nature is strong.

Customizable various types of non-standard products, such as explosion-proof, sealed vacuum, multi-cylinder, etc. The material can be customized as SS21 or SS316L stainless steel according to requirements.

The dispersion disc of the wall-scraping hydraulic disperser operates at high speed, causing the material to form a circular flow and generate a strong vortex, which spirals down to the bottom of the vortex. Intense shear, impact, and friction occur between particles, achieving rapid dispersion and dissolution. The PTFE wall scraper rotates in close contact with the container wall, scraping it to resolve the issue of material adhesion while accelerating material circulation. The hydraulic pump drives the hydraulic plunger to lift and lower, thereby moving the entire transmission mechanism and working group.

Product Details
