Product Overview
The pneumatic lifting disperser features dispersion and mixing functions. It is a pilot-scale product widely used in small-batch production in factories, research institutions, colleges, and universities. The equipment is equipped with a frequency converter for stepless speed regulation, allowing for long-term operation with stable performance and low noise. The mixing disc is easy to disassemble. The lifting structure uses a pneumatic cylinder as the actuator, which is environmentally friendly and pollution-free, making it an ideal device for small-batch production.

Product Features

High dispersion efficiency and excellent product quality.

The equipment can reach a speed of **1500 rpm** and a linear velocity of over **20 m/s**, enabling rapid and uniform dispersion of powder into liquid materials. Due to the extremely high shear force applied, the materials are evenly dispersed, resulting in excellent suspension effects.

Easy to operate and safe.

The equipment uses a cylinder as the lifting actuator, with a pneumatic control valve to manage the disperser's ascent, stop, and descent. It features low air consumption and simple operation. The dispersion disc is secured to the main shaft with hex socket bolts, allowing for quick and easy disassembly, replacement, and cleaning. It is equipped with a manual barrel clamping device that can quickly secure the mixing barrel, preventing displacement during operation and ensuring safety.

Easy to move

The equipment occupies a small footprint and is equipped with casters and brake devices for easy fixation and mobility.

The non-standard nature is strong.

Customizable various types of non-standard products, such as explosion-proof and sealed types. The material contact parts can be customized with SS304, SS316L, Hastelloy, titanium-molybdenum-nickel alloy, and other materials.

The pneumatic lifting disperser utilizes the high-speed rotation of the dispersion disc to create a circular flow of the material, generating a strong vortex that spirals downward to the bottom of the vortex. This process results in intense shear, impact, and friction between particles, achieving rapid dispersion, dissolution, and uniform mixing. The cylinder is operated by rotating the pneumatic valve or using solenoid valve jog control, and the lifting of the cylinder drives the motor and working head to move up and down.

Material Viscosity: ≤25,000 cps

Production Capacity: 100-500L

Application Areas: Suitable for the dispersion and mixing of product materials in industries such as biology, pharmaceuticals, food, coatings, inks, adhesives, dyes, and pesticides.

Applicable materials: Various slurries with a viscosity below 25,000 cps and a solid content below 60%, such as latex paint, industrial paint, water-based ink, pesticides, adhesives, and thousands of other materials.
