The disc horizontal sand mill is a continuous-operation, closed-type wet grinding equipment. It features simple operation, good reliability, and a complete range of specifications, making it one of the most widely used wet grinding devices on the market, with highly mature performance and structure. The sealing structure adopts a double-end-face mechanical seal, equipped with a cooling system for the double-end-face mechanical seal, ensuring reliability and durability. It includes temperature and pressure monitoring and protection to guarantee product quality. The use of zirconium oxide beads offers advantages such as high grinding efficiency, excellent fineness, wide application range, and good wear resistance.

Product Features

Low energy consumption ratio, high cost-effectiveness.

The equipment drive uses a motor to transmit power to the main shaft through large and small pulleys, making startup easy. The grinding disc adopts a specially designed circular structure, which ensures high efficiency while consuming less electricity. It is a cost-effective product among grinding machine equipment.

Easy to operate and clean.

The equipment features a field operation box integrated into the frame for convenient operation. It is equipped with a bead collection hopper, and the grinding chamber is designed for easy disassembly from the frame. A pulley mechanism allows the cylinder to be detached, effectively enabling thorough cleaning of the chamber and zirconium beads, making it suitable for materials of different colors and varieties.

Safety monitoring, product stability.

The grinding chamber is equipped with a special cooling water jacket, which allows water to flow through for cooling during operation, achieving excellent cooling effects with a typical temperature rise of less than 10°C. The device features temperature and pressure monitoring, allowing the setting of "protection values" to ensure product quality.

Complete specifications, with non-standard customization available.

Equipment specifications range from 10L to 100L, covering a full range of sizes; explosion-proof models can be customized, and the grinding chamber can be lined with polyurethane as a non-standard option.

The diaphragm pump of the disc-type horizontal sand mill circulates the material between the material tank and the grinding chamber. The grinding media with a high filling rate in the chamber are driven by the rotating disc, generating forces in various directions and irregular movements. The particles in the material are continuously collided and rubbed by the grinding media. Meanwhile, the screen separates the material from the grinding media, allowing the material to continuously circulate from the material tank to the grinding chamber. This achieves the goal of reducing particle size and narrowing the particle size range.

Material Viscosity: ≤20,000 cps

Production Capacity: 20-2000L

Application: Suitable for the dispersion and grinding of product materials in industries such as biology, pharmaceuticals, cosmetics, food, coatings, inks, color pastes, dyes, and pesticides.

Applicable Materials: Materials with a viscosity below 20,000 cps and high fineness requirements, such as latex paint, industrial paint, color paste, water-based ink, pesticide suspension concentrate, lithium battery slurry, and thousands of other materials.
