Product Introduction

The laboratory nano horizontal sand mill is a high-performance nano-level wet grinding equipment. This equipment operates in a continuous mode and uses imported ultra-fine pure zirconia beads, offering advantages such as high grinding efficiency, excellent fineness, wide application range, and good wear resistance. Additionally, the chamber is lined with zirconia, which not only significantly reduces component wear and extends service life but also greatly minimizes contamination of the material being ground. The increased cooling area and efficiency address the challenge of heat dissipation. The self-circulation system eliminates the need for an additional transfer pump, reducing cleaning difficulty. This equipment is widely used in industries such as coatings, inks, pigments, color pastes, cosmetics, pesticides, and pharmaceuticals.

Product Features

The equipment's motor drives the internal feeding device to rotate at high speed, creating negative pressure. Through self-priming action, the material in the upper tank is sucked in and delivered to the grinding chamber. The high-fill-rate grinding media inside the chamber are driven by the rotating dial, generating forces in various directions and moving irregularly. The particles in the material are subjected to continuous collision and friction from the grinding media. Meanwhile, the screen separates the material from the grinding media, allowing the material to circulate continuously from the tank to the grinding chamber. This achieves the goal of reducing particle size and narrowing the particle size range.

Product Structure

1. Suitable for grinding small amounts of materials in the laboratory, with a grinding jar capacity of 0.5L.
2. Good grinding fineness: imported 0.8-1.0 pure zirconia beads are used, and the **grinding fineness can reach 300 nanometers.
3. High grinding efficiency: for the same product and the same fineness, the grinding time is only two-thirds of that required by traditional equipment.
4. The grinding chamber and moving parts are made of ceramic materials to reduce equipment wear and contamination of materials.
5. Adjust the rotation speed as needed to achieve the **optimal grinding effect**.
6. Built-in self-priming pump system reduces the need for cleaning the delivery pipeline.

Product Details

Model: LSN0.5

Power supply: 220/380V, 50HZ

Power (kW): 1.5 kW

Frequency Converter: Variable Frequency Speed Control

Speed r/min: 50-3000

Simplified Volume L: 0.5L

Efficiency kg/h: 5-30

Limit Grinding Fineness (nm): 300

Internal wear parts: precision ceramics, durable, non-contaminating to materials (including ceramic dials, ceramic bushings)

Zirconia bead diameter mm: 0.8-1.2mm

Standard zirconia bead weight KG: 1.2kg

Configure one 0.8L jacketed vessel and one set of cooling water pipes.

Overall dimensions mm: 880X435X620mm (Length X Width X Height)

Machine weight kg: 68kg

Product Logistics Packaging Instructions

The equipment is packaged in eco-friendly wooden crates and is ready for direct export.

Application Areas

Paint, pharmaceuticals, biosciences, batteries, ceramics/Glass, pigment/Fuels, printing inks, cosmetics, food, adhesives/Sealant, ore/Mineral/Metals, fluorescent whitening agents,Cellulose/Pulp, coatings, microelectronics, and semiconductorsNano applications, agrochemicals Life SciencesResearch/Teaching
