Product Overview

The laboratory three-roll mill is primarily used for grinding paste-like materials such as various inks, paints, pigments, soaps, artificial leather, plastics, lubricating grease, chocolate, and welding materials. It is especially suitable for grinding products with high viscosity and strict fineness requirements. The machine features high surface hardness and wear resistance, along with a cooling device to ensure continuous operation. It is easy to operate, occupies a small footprint, and is widely used in laboratory scientific research and new product development.

Product Features

The three-roll mill achieves grinding through the mutual compression of the surfaces of three horizontal alloy rollers and friction at different speeds. The transmission uses a belt pulley system for noise-free operation, with gears fully immersed in lubricating oil to **maximize the machine's service life while reducing noise and energy consumption. The rollers are made of wear-resistant alloy steel, ensuring long-lasting durability.

Product Structure

1. The fineness achievable through grinding is **one of the best** in wet grinding equipment;

2. Manual adjustment of roller gap, with a simple and reliable mechanism;

3. Suitable for processing high-viscosity materials;

4. The roller gap is adjustable;

5. Both the inlet and outlet can be customized with temperature display to ensure that the materials being processed are not affected by temperature changes, thereby maintaining product quality.

6. The top roller adjustment structure of the roller grinding machine has been changed to a gear adjustment roller, which is smoother, lighter, and more durable and stable in operation.

Product Details

Product Model: LSG65
Motor Power: 750W
Power supply: 220V/50Hz
Roller diameter: 65mm
Roller working width: 125mm
Slow roller speed: 32 rpm
Middle roller speed: 89 rpm
Fast roller speed：250rpm
Material of the roller:Hard stainless steel/ceramic
Contact Material: SUS304
Support Material: Q235-A
Transmission Form: Gear Transmission
Accessories:Ingredient tray, scraper
Overall dimensions: 410x550x450mm
Machine weight: 85kg

Application Areas

Paint, pharmaceuticals, biosciences, batteries, ceramics/Glass, pigment/Fuels, printing inks, cosmetics, food, adhesives/Sealant, ore/Mineral/Metals, fluorescent whitening agents,Cellulose/Pulp, coatings, microelectronics, and semiconductorsNano applications, agrochemicals Life SciencesResearch/Teaching
