Product Overview
The semi-automatic filling machine uses the gravimetric method for measurement, controlling the opening of the feed valve through signals from a load cell to achieve automatic filling. The front end of the feed port is equipped with a feed pump or a method of pressurizing the raw material storage tank to transport the material from the tank to the filling machine. Before filling, a filtration device can be added to remove impurities, ensuring product quality. This equipment offers high filling efficiency and low filling error, and is widely used in industries such as coatings, inks, paints, asphalt, adhesives, lubricating oils, petrochemicals, and fine chemicals. It is suitable not only for filling fluids but also for filling paste products.

Product Features

Fast filling speed, wide range of applications.

The filling head adopts a single-head design with fast and slow dual-speed filling, which effectively increases filling speed, reduces costs, and alleviates workers' workload. Due to its weighing-based design, it is suitable for filling round, square, flat containers, and various bottle neck sizes.

Easy to operate and maintain.

Personalized design allows one person to complete the operation, set the specified filling volume, and achieve automatic zeroing with a single press of the filling button, along with an automatic tare function. It uses roller conveyor, allowing the operator to adjust the barrel placement position according to their habits for filling.

High filling accuracy and high level of intelligence.

Using a branded load cell, the scale platform accuracy can reach over 0.02%, ensuring filling precision. It is equipped with an automated control instrument to achieve automatic feeding. Features include automatic zeroing upon startup and automatic tare removal. Intelligent advantages such as automatic weight error correction, power-off protection, fault detection, and the ability to restore factory settings after incorrect operations are clearly evident.

Excellent environmental performance and safety.

The filling feed uses pipeline connections, with multiple connection options available. After filling is completed, the capping/clamping process is carried out quickly, minimizing solvent evaporation and ensuring a good on-site environment. The length of the filling machine's track can be customized as needed.

The automation control instrument receives the weight signal from the weighing sensor and controls the feeding valve through single-head/large flow/small flow modes to achieve automatic filling. It is also equipped with a semi-automatic conveyor roller track and a capping/clamping device to complete the material filling and sealing process.

Material Viscosity: ≤50,000 cps

Production Capacity: 500-50,000ml

Application: Suitable for filling materials in industries such as coatings, inks, adhesives (glue), resins, chemical solvents, lubricating oils, and pesticides.

Applicable Materials: Liquid and slurry materials with a viscosity below 50,000 cps and a certain degree of fluidity, such as cooking oil, latex paint, color paste, industrial paint, curing agents, organic solvents, water-based ink, pesticide suspensions, adhesives, detergents, and thousands of other materials.
