Product Introduction
The dual-head semi-automatic filling machine adopts the gravimetric method for measurement, utilizing signals from load cells to control the opening of the feed valve, thereby achieving automatic filling. The front end of the feed port is equipped with a feed pump or a method of pressurizing the raw material storage tank to transport the material from the tank to the filling machine. A filtration device can be added before filling to remove impurities and ensure product quality. This equipment offers the advantages of high filling efficiency and minimal filling error. It is widely used in industries such as coatings, inks, paints, asphalt, adhesives, lubricants, petrochemicals, and fine chemicals. It is suitable not only for filling fluids but also for filling paste-like products.

Product Features

Fast filling speed, wide range of applications.

The filling head adopts a single-head filling mechanism with fast and slow dual-speed filling, which effectively improves filling speed and reduces costs. It alleviates the work pressure on workers; due to its weighing-based design, it is suitable for filling round, square, flat, and various other bottle neck sizes.

Easy to operate and maintain.

Personalized design allows one person to complete the operation, set the specified filling volume, and achieve automatic zeroing and tare with a single press of the filling button. It adopts roller conveyor, allowing the operator to adjust the barrel placement position according to their habits for filling.

High filling precision, high level of intelligence.

Using a branded load cell, the scale platform accuracy can reach over 0.02%, ensuring filling precision. It is equipped with an automated control instrument to achieve automatic feeding. Features include automatic zeroing and auto-tare upon startup. Intelligent advantages are evident, such as automatic weight error correction, power-off protection, fault detection, and the ability to restore factory settings after incorrect operations.

Excellent environmental performance and safety.

The filling feed uses pipeline connections with multiple connection options. After filling is completed, the capping/clamping process is quickly finished, resulting in minimal solvent evaporation and a good on-site environment. The length of the filling machine's track can be customized as needed.

The dual-head semi-automatic filling machine's automation control instrument receives weight signals from the load cell, and controls the feed valve through single-head/large flow/small flow modes to achieve automatic filling. It is also equipped with a semi-automatic conveyor roller track and a capping/clamping device to complete the material filling and sealing process.

Material Viscosity: ≤50,000cps

Production Capacity: 500-50,000 ml

Application: Suitable for filling materials in industries such as coatings, inks, adhesives (glue), resins, chemical solvents, lubricating oils, and pesticides.

Applicable Materials: Liquid and slurry materials with a viscosity below 50,000 cps and a certain degree of fluidity, such as cooking oil, latex paint, color paste, industrial paint, curing agent, organic solvents, water-based ink, pesticide suspension concentrate, adhesives, detergents, and thousands of other materials.

Product Details
