Product Image
Product Features
The stirring paddle inside the kettle rotates both in revolution and self-rotation, causing the material to flow vertically and horizontally, thereby achieving the mixing (kneading) effect in a very short time.
Low-speed blades are available in various types, including framed, paddle, and twisted-frame designs.
Vacuum design ensures that materials operate in a sealed environment.
The heating method for the V-shaped kettle body can be electric heating, steam heating, hot water, or external circulation of hot oil, with an intelligent temperature controller for precise temperature control.
Product Details
Model/Type | LSXJ02 | LSXJ05 | LSXJ100 | LSXJ200 | LSXJ500 | LSXJ1000 |
Specifications of the Mixing Tank | Φ180*120/150 | Φ240/288*180 | Φ600*460/500 | Φ720/750*650 | Φ1000*380 | Φ1250*1000 |
Total volume L | 3/3.8 | 8/11.7 | 130/140 | 265/287 | 650 | 1227 |
Effective Volume L | 2 | 5 | 100 | 200 | 500 | 1000 |
Motor Power (kW) | 0.37-0.75 | 0.55-1.5 | 4-11 | 7.5-15 | 15-37 | 30-55 |
Stirring speed RPM | 0-100 | 0-100 | 0-100 | 0-80 | 0-60 | 0-50 |
Revolution/scraping wall rotation speed | 0-60 | 0-60 | 0-60 | 0-50 | 0-40 | 0-30 |
Lifting stroke (mm) | 220 | 270 | 560 | 750 | 930 | 1100 |
Vacuum degree (MPa) | -0.098- -0.08 | -0.098- -0.08 | ||||
