Sulfur Preparation Mill, Inert Gas Protection Mechanical Grinder

1. Working Principle

It is based on the ordinary high-efficiency impact mill and the vertical turbine high-precision classifier.Designed and developed specifically for flammable, explosive, and easily oxidizable materials by altering the airflow composition, modifying the equipment's air intake and exhaust pipelines, and improving the sealing process of the equipment. The entire system uses inert gas as the fluid working medium. The complete equipment consists of an inert gas source, an oxygen content tester, an intake pipeline system, a closed-loop feeding system, a vertical turbo classifier, an induced draft fan, a sealed replacement discharge valve, an anti-static pulse reverse-jet dust collector, and an inert gas replenishment device. The outlet of the induced draft fan is connected to the inlet of the high-efficiency impact mill, forming a closed-loop inert gas circulation system.

Performance Features

The entire production line operates in a fully enclosed negative pressure circulation mode.PLC programming control is adopted to minimize manual operation and control factors. The control cabinet can be placed in a separate control room at a distance. On-site monitoring can be achieved through surveillance cameras, enabling fully unmanned operation.
