Product NameGTDZ Electromagnetic Wet Powder Iron Remover

Processing capacity:8-140m³/h

Inlet slurry concentration:10-25%

Cooling method: Oil-water composite

Application Fields: Used for iron removal and purification of non-metallic minerals such as quartz, feldspar, and kaolin. It can also be applied to wastewater treatment in iron and steel mines and power plants, as well as cleaning contaminated chemical raw materials.

Device Introduction:The GTDZ series electromagnetic slurry high-gradient magnetic separator is a **magnetic separation product** developed by our company. It features a background magnetic field of up to 1.5T, a high magnetic field gradient, and can be equipped with various specially designed magnetically conductive stainless steel media to meet the beneficiation needs of different types of minerals in various regions.

Highlight advantages:

◆ Unique electromagnetic coil design and efficient cooling method.
The excitation coil of the electromagnetic slurry high-gradient magnetic separator is cooled using fully sealed cooling oil, with an external high-efficiency heat exchanger facilitating oil-water heat exchange to achieve composite oil-water cooling. This results in fast cooling speed, low temperature rise, and stable magnetic field.
◆The sorting medium generates an extremely high magnetic field gradient, resulting in better iron removal efficiency.
The medium is made of specially designed magnetically conductive stainless steel, which can generate an extremely high gradient magnetic field when excited by the background magnetic field. It has a strong adsorption effect on low-content weakly magnetic impurities, resulting in better iron removal performance.
◆ Fully automated operation with low running and maintenance costs.
The operation process of this equipment is controlled by automated programs, enabling unattended fully automatic operation, thereby reducing operational and maintenance costs.
◆ High-pressure water forward and reverse flushing ensures thorough iron removal with no residue.
When the equipment removes iron, high-pressure water is used to clean the medium, ensuring thorough iron removal. The cleaning time can be set separately based on different minerals and different stages of iron removal, thereby improving processing efficiency.
