Product Name: Experimental Jet Mill

Feed particle size:≤1mm

Production capacity1-30kg/h

Application: Screening and classification experiments of ultrafine powders

Materials: Silicon micro powder, calcium carbonate, feldspar powder, aluminum oxide, bauxite, kaolin, talc, graphite, etc. (Corresponding small images can be added after setting, refer to Red Star, and we will supplement them later.)

Equipment Introduction: The experimental use of an air jet mill is a small-scale device developed for processing small batches of materials and high-value materials.

Highlight advantages:

1、Crushing and classification are integrated, with adjustable product particle size.

2、It has both particle dispersion and particle shaping functions.

3. Quick-opening structure, easy to clean and maintain, compliant with GMP requirements.
4. It adopts PLC automatic control or electromechanical control, ensuring reliable operation and simple operation.

Working Principle IntroductionCompressed air, after cooling, filtration, and drying, forms a supersonic airflow through nozzles and is injected into the crushing chamber. The accelerated materials converge at the intersection point of the jet streams from multiple nozzles, resulting in intense collision, friction, and shearing, achieving ultra-fine crushing of particles. The crushed materials are transported by the rising airflow to the impeller classification zone, where, under the combined action of the centrifugal force of the classification wheel and the suction force of the fan, coarse and fine powders are separated. The coarse powder returns to the crushing chamber under its own gravity for further crushing, while the qualified fine powder enters the cyclone collector with the airflow. Microfine dust is collected by the bag filter, and the purified gas is discharged by the induced draft fan.
