Applicable Materials: Can be used for hard materials such as quartz, feldspar, alumina, bauxite, and zircon sand; also suitable for soft minerals like calcite, marble, limestone, and barite.
The entire production line system operates under negative pressure, ensuring absolutely no dust leakage throughout the entire production process, making it environmentally friendly and pollution-free. The production line adopts centralized control, which reduces labor intensity for workers and ensures product quality.
This production line features minimal material contamination, stable product quality, and controllable particle size distribution.

Working Principle Introduction
After grinding, the material enters the classifier through the feed inlet. By adjusting the rotational speed of the classifying wheel and incorporating a reasonable secondary air intake, a stable and well-balanced gas-solid two-phase flow is formed within the classification zone. Effective classification of the material is achieved through the interaction between the centrifugal force generated by the rotation of the classifying wheel and the suction force produced by the negative pressure of the induced draft fan.
Coarse particles are returned to the ball mill by the coarse material return device for further grinding, while the finished product is packaged by an automatic packaging machine. The entire system is equipped with a dust collector, which employs advanced electromagnetic pulse automatic cleaning. After dust-laden gas enters the dust collector, the dust is filtered by filter bags. The dust attached to the outer surface of the filter bags is scattered and collected at the bottom under the action of pulse back-blowing gas. The filtered clean gas is then discharged into the atmosphere through a fan.
Using quartz material or aluminum oxide ceramic material, the internal parts of the classifier system are lined with aluminum oxide ceramic sheets for ultra-pure wear-resistant protection. The classifier impeller blades are made of high-molecular wear-resistant materials, effectively solving the problem of iron contamination during equipment wear!International standard production line, which can be customized, designed, and manufactured according to customer requirements.

Technical Parameters
