Dry Powder Mixer Instructions:
The dry powder mixer operates with low-speed, dual-radial three-dimensional mixing, making it suitable not only for general material mixing across various industries but also for mixing materials with high oil content, high sugar content, flammable and explosive properties, or those prone to heating, curing, or transformation (e.g., pharmaceuticals, food additives, chemical auxiliaries, textile sizing agents, etc.). Particularly for powder coatings, it is applicable for post-mixing of finished powders, especially for special powders such as textured, two-tone, and metallic powders, as well as for post-mixing of recycled powders, ultrafine powders, and finished powder blending. It can also be used for mixing finished products with loosening agents (aluminum trioxide) and for large-capacity pre-mixing of powder coatings. Additionally, it is widely used in industries such as food, pharmaceuticals, pesticides, zinc oxide, detergents, veterinary drugs, compound fertilizers, feed, petroleum, metallurgy and mining, building materials, coatings, dyes, pigments, auxiliaries, calcium carbonate, biotechnology, ceramics, chemicals, flavors and fragrances, chicken essence, seasonings, tea, grains, starch, plant fibers, milk powder, cocoa powder, flour, coffee, glucose, and more.
Principles and Features of Dry Powder Mixer
The dry powder mixer is suitable for mixing crushed materials of different specific gravities or adding other additives.
The use of internal and external rotary mixing ensures high uniformity.
The mixing drum can be tilted at any angle to facilitate discharging and cleaning.
Equipped with an automatic timer, it can be set to automatically stop within 0 to 60 minutes.
The use of stainless steel butterfly valves for material discharge ensures no dust leakage or flying dust occurs.
Mixed using the principle of gravity diffusion, it exerts minimal compression on the material and does not cause shear crushing.
The cylinder is made of high-quality stainless steel, with both the inner and outer walls polished. It ensures no contamination of materials during the mixing process, has low power consumption, and is easy to clean.
Simple to operate, easy to clean, suitable for use in G.M.P food and pharmaceutical factories.
Large-capacity mixers can be equipped with a vacuum feeding system to improve work efficiency and enhance the working environment.

W-type Technical Parameters：
