YSN-0.6L Laboratory Nano Bead Mill
Here is the English translation of "简介:": **Introduction:**
The Yongyan Rod-Type Nano Sand Mill is a new type of high-flow circulation sand mill.It is the essence of current ultra-fine grinding equipment.
Product Details
Model:YSN-0.6L
I'm sorry, but you've only provided a single Chinese character "永" (yǒng), which means "eternal" or "forever." Could you please provide the full text you'd like me to translate?The extended rod type nano sand mill is a new type of high-flow circulation sand mill.It represents the essence of current ultra-fine grinding equipment. The use of a cyclic sand milling process or multiple grinding processes can increase production capacity and optimize the particle size distribution of the product. With a few additional control functions, product reproducibility can be ensured, and costs can be saved. The large-sized rotor combined with a cylindrical gap-type separator allows this type of equipment to use small-diameter grinding media made of different materials. For materials that require protection from metal contamination, ceramic (silicon carbide, silicon nitride, zirconium oxide) and polyurethane structural materials can be used.
◆ Features: Suitable for wet nano-grinding in all related industrial applications, offering flexible production and a wide range of uses.
◆ Applications: Water-soluble products, oil-soluble products, pollution-free products, and alcohol-based products, suitable for machinery and engineering in various industries and applications.
Model | Experimental grade | Production-grade | ||||||
YSN-0.3L | YSN-0.6L | YSN-1L | YSN-6L | YSN-10L | YSN-30L | YSN-60L | YSN-150L | |
magnification factor [l] | - | - | 0.08 | 0.2 | 0.5 | 2 | 4 | 8 |
Grinding chamber capacity [l] | 0.3 | 0.6 | 1 | 6 | 10 | 30 | 60 | 150 |
Better Grinding Batch[l] | 0.3-1 | 1-2 | 2-10 | 100-600 | 100-500 | 500-2000 | >2000 | >4000 |
Flow rate [kg/h] | 10-50 | 100-300 | 180-380 | 40-200 | 100-500 | 500-2500 | 1000-6000 | 2000-1500 |
Power [kW] | 1.5 | 3.7 | 3.7 | 15 | 22 | 45 | 75 | 160-200 |
Application Areas
