Product Introduction
The laboratory variable frequency disperser is a small-scale dispersion and mixing equipment designed to meet the needs of universities, research institutions, and factory laboratories. It integrates multiple functions such as sand grinding, dispersion, and stirring, offering various advantages. The lifting system adopts a spring sleeve structure, making it convenient and labor-saving. It uses a variable frequency motor with a brushless design, ensuring a long service life and low noise. For ease of operation, the frequency converter is directly installed on the machine, and the display screen directly shows the spindle speed. The lifting structure is simple and easy to operate, making it an ideal experimental device for laboratories.

Product Features

1. Stainless steel dispersion disc

2. Variable Frequency Speed Control

3. Cylindrical stainless steel barrel with a rounded bottom and interlayer.

4. Safety clamp for the material barrel

5. Manual Silent Lifting System

The serrated circular dispersion disc of the disperser operates at high speed within the container to complete the processes of solid-liquid dispersion, wetting, deagglomeration, and stabilization. This causes the slurry to form a rolling annular flow, generating a strong vortex, with particles on the slurry surface descending in a spiral pattern to the bottom of the vortex. A turbulent zone forms 2.5-5mm from the edge of the dispersion disc, where the slurry and particles undergo intense shear and impact. Outside this zone, two upper and lower streams are formed, allowing the slurry to be fully circulated and turned over. Below the dispersion disc of the disperser, a laminar flow state is present, where slurry layers at different flow velocities diffuse into each other, achieving the dispersion effect.

Material Viscosity: ≤25000 CPS

Production Capacity: 0.2-50L

Applicable Materials: Various non-flammable and non-explosive slurries with a viscosity below 25,000 cps and a solid content below 60%, such as latex paint, industrial paint, water-based ink, and thousands of other materials.

Application Areas: Suitable for the dispersion and mixing of product materials in industries such as biology, pharmaceuticals, food, coatings, inks, adhesives, dyes, and pesticides.

Product Details
