Product Name:GCX|| Series Permanent Magnetic Drum Separator

Magnetic Field Strength:1000-10000GS

Production capacity≤5-15T/H

Application: Removal of iron contaminants from powdered or fine granular materials, used for the purification of non-metallic minerals such as refractory materials, glass, ceramics, and abrasives, as well as for the removal of impurities in chemicals, grains, and non-magnetic metal ores, and for dry pre-concentration of hematite and limonite.

Device Introduction:GCX||Series Permanent Magnetic Drum Separators are primarily used to remove iron contaminants from powdered or fine granular materials. This product requires no maintenance and is safe and reliable to use.

Highlight advantages:

1. Rare earth permanent magnet materials, when used as magnetic sources, can achieve a magnetic field of up to10,000 Gauss, high magnetic penetration depth, strong suction force.

2. Equipped with a vibrating feeder for uniform feeding, the feed rate can be adjusted and controlled, enabling continuous and automatic removal of impurities.

3. Configure a cross or flip magnetic field, which can be made into a two-cylinder or multi-cylinder type.

4. The new compensation magnetic pole type magnetic system achieves higher magnetic field intensity and greater gradient.

5. The whole machine is maintenance-free, safe and reliable to use.
